  • Solar Ground system Galvanized steel flexible fixed bracket
  • Solar Ground system Galvanized steel flexible fixed bracket
Product introduction

The flexible fixed bracket system uses the height difference between the front and rear columns to achieve the inclination angle of the component.Galvanized steel strands are used as the main load-bearing cable,in order to control the sag and deformation of the steel strands of the flexibl0e support system and reduce its internal force.

Physical Properties
Type Photovoltaic stents
Material Material Carbon steel
Surface finishing/treatment

Pre-galvanized 8um/ Electro zinc Plating(≥12um)

Hot -dip galvanized(>60um)

Plastic-spayed(>60um)

Power coating

Dimension range

customizable is available

Width Customizable is available
Side Rail Height
Length
Thickness/wire diameter
Max. Working Load
Accessories/related products
Product Features

1. Adaptable

2. High cost performance

3. Easy installation

Color

Design wind pressure: 0.55KN/㎡

Design snow pressure: 0.5KN/㎡

Service life: 30 Years

Enviroment demmand
Application Requires a large span requirement scenario
Flexible fixed · Steel strand carrier
Solar Ground System Galvanized Steel Flexible Fixed Bracket

The Solar Ground System Galvanized Steel Flexible Fixed Bracket is a specialized support structure system designed for ground-mounted photovoltaic power plants. This system employs a unique flexible fixed structure that utilizes the height difference between front and rear columns to achieve the optimal tilt angle for photovoltaic modules. Galvanized steel strands serve as the primary load-bearing cables, ensuring structural stability while effectively controlling sag deformation and reducing internal forces within the support system.

15° – 35°
tilt angle range
-30% weight
compared to conventional rigid structures
ASTM A123
hot-dip galvanized coating
dual protection
barrier + electrochemical

Structural Characteristics

Hot-dip galvanized steel material with coating thickness compliant with ASTM A123 standards, ensuring long-term weather resistance in outdoor environments
Flexible support structure design enabling system tension control through steel strand pre-stress adjustment
Adjustable front and rear column heights supporting installation tilt angles from 15° to 35°
Modular component design facilitating rapid on-site assembly and reduced installation time

Technical Advantages

Steel strand load-bearing structure adapts to various foundation conditions, minimizing site leveling requirements
System weight approximately 30% lighter than conventional rigid structures, reducing transportation and installation costs
Galvanized steel surface treatment provides dual corrosion protection: barrier protection and electrochemical protection
Adjustable support spacing compatible with multiple standard photovoltaic module dimensions
Wind load and snow load analysis verified according to international building code requirements

Application Scope

  • Utility-scale ground-mounted photovoltaic power plants
  • PV projects on uneven terrains including hills and slopes
  • Agricultural-photovoltaic complementary projects
  • Commercial and industrial distributed photovoltaic power stations

Installation & Maintenance

  • Detailed installation guidance documents provided, including foundation construction requirements and torque parameters
  • Standard tools sufficient for most installation procedures
  • Regular inspection items include fastener tightness status and steel strand tension values
Pre-stress adjustment must be performed after column alignment verification. Tension values should be rechecked within 30 days post-installation.
