Embedded pile photovoltaic mounting system for mountain photovoltaic power station

Inquiry

PREV：Solar Ground system Galvanized steel flexible fixed bracket NEXT：Single column photovoltaic mounting system

Product introduction

Embedded pile photovoltaic mounting system is mainly suit for ground photovoltaic power station and mountain photovoltaic power station. The system has low demand for terrain, it is suitable for a variety of complex terrain , especially in mountainous areas. It is easy to install, which can meet the needs of customers.

Physical Properties

Type		Photovoltaic stents
Material	Material	Carbon steel
	Surface finishing/treatment	Pre-galvanized 8um/ Electro zinc Plating（≥12um） Hot -dip galvanized（＞60um） Plastic-spayed（＞60um） Power coating
Dimension range customizable is available	Width	Customizable is available
	Side Rail Height
	Length
	Thickness/wire diameter
	Max. Working Load
Accessories/related products
Product Features		1. Strong ability to adapt to terrain 2. Easy installation 3. High structural strength
Color		Design wind pressure: 0.55KN/㎡ Design snow pressure: 0.5KN/㎡ Service life: 30 Years
Enviroment demmand
Application		Ground or mountain terrain

Mountain terrain · embedded foundation

Embedded Pile Photovoltaic Mounting System

The Embedded Pile Photovoltaic Mounting System is a ground support structure specifically engineered for complex terrains, particularly mountainous environments. This system stabilizes PV modules by embedding pile foundations directly into the ground, offering a reliable solution to address slope variations and geological challenges in mountain projects.

▍Key System Characteristics

Terrain Adaptive Structure

The design imposes low demands on ground flatness. It allows flexible adjustment according to mountain slopes, reducing the need for extensive preliminary earthworks and site leveling.

Modular Component Design

Comprises prefabricated standard parts. Components are primarily connected via bolts on-site, which simplifies the installation process and can contribute to shorter construction periods.

Embedded Pile Foundation

Utilizes piles driven directly into the ground as the primary support, creating a firm integration with the soil layer to provide wind resistance and anti-overturning stability for the superstructure.

High-Strength Steel Main Structure

The supporting framework is manufactured from high-strength steel. Components typically feature a hot-dip galvanized surface treatment to ensure long-term corrosion resistance in outdoor environments.

▍Operational Advantages

Reduces Civil Works Costs – By adapting to the original terrain, the system significantly minimizes land leveling and the use of concrete foundations, helping to control initial project civil costs.

Enhances Installation Efficiency – The modular design and simplified installation steps lower the technical difficulty of on-site construction and reduce dependence on large machinery, thereby improving overall installation efficiency.

Solution for Complex Terrain – Provides a viable construction solution for PV power stations on uneven land such as hills and mountains, expanding potential site selection for PV projects.

Structural Stability – The embedded pile foundations deliver reliable anchoring force, ensuring the structural safety and stability of the PV array under severe weather conditions.

▍Primary Application Fields

Photovoltaic power stations in mountainous and hilly regions

Ground-mounted distributed PV power plants

Commercial and industrial ground PV projects on complex terrain

Agri-photovoltaic and Silvo-photovoltaic complementary projects

⛭

Embedded pile depth and diameter are determined based on geological survey results and local wind load requirements. Hot-dip galvanized coating thickness ≥80μm per ISO 1461.
